QAL 260
MCERTS Approved Back Scatter Particulate CEM
MCERTS QAL1 approved, stand alone or multi-sensor Particulate CEM providing high quality emission measurement for low dust concentrations from dry industrial processes.
FEATURES AND BENEFITS
- ProScatterโขย Backscatter sensor technology with superior minimum detection <1mg/m3
- Certified to 15 mg/m3ย for processes with low typical emission limits
- Manual and remote Zero and Span (reference) checks available to ensure optimal instrument performance and to comply with EN 13284/QAL1
- Automatic Functionality Check โ fully interrogates the optical system
- Purge Flow Fail Sensor option with inbuilt automatic optical shield activation
- Flue Gas Blocker option to protect Plant Engineers from harmful flue gases during maintenance
MAIN APPLICATIONS
- Stacks after bag filters, cartridge filters, cyclones, electrostatic precipitators, no filtration
- Non-condensing / dry flue gases
- Incineration
- Metals (e.g., Steel/Aluminium)
- Minerals (e.g., Cement/Gypsum)
- Chemicals (e.g., TiOโ / Coating Powder)
- Power Generation Plant (e.g., Coal/Biomass)
TECHNICAL INFORMATION
Measured parameters
Dust
Technology
ProScatterโข Backscatter
Measurement/Monitoring capability
0 โ 500 mg/m3*
Stack/Duct diameter suitability
up to 10m
Flue gas temperature
up to 400ยฐC
Baghouse
YES
Cartridge Filter
YES
Ceramic Filter
/
Coalescent Filter
/
Cyclone
YES
Electrostatic Precipitator (ESP)
YES
Wet Electrostatic Precipitator (WESP)
/
Wet Scrubber
/
Sensor variants
Stainless Steel
QA checks
YES
Measurement capability
0 โ 500 mg/m3
Sensor Variants
316 Stainless Steel
Stack Temperature Ranges
-20ยฐC โ 250ยฐC up to 400ยฐC option
Functionality and QA Checks
Automatic zero and span
Data Output
RS485 (Modbus) output to Controller
Air Purge
option
Enclosure Protection Rating
IP65
APPROVALS & CERTIFICATIONS
Certificates:
- MCERTs certified to EN15267-3
- QAL1 as defined by EN14181
- QAL3 compliance to EN14181
